Exclusive Adjustable Lock Ladder Leveling System to enable level runways at all lock heights – even on uneven floors
20” wide runways for wider vehicles
Multiple height lock positions to work at a comfortable height or store a vehicle at a height that works with your ceiling height
Operate the lift from one column with the Power Unit and single point lock release
Power unit and lock release can be mounted to any column that works best for your garage
Steel approach ramps
Durable black powder coat finish
Powered with standard 115V plug included
Capacity
9,000 lbs
Max Rise
84"
Clearance Under Runways
79 1/4"
Overall Length
193 1/8" Without Approach Ramps, 225 1/2" With Approach Ramps
Overall Width
121 1/2" Without Motor, 132 1/2" With Motor
Approach Ramp Length
37"
Runway Width
20"
Runway Length
184 1/2"
Runway Height
4 3/4"
Drive Through Width
97"
Column Height
97"
Clearance Between Columns
109 1/2"
Clearance Between Runways
39"
Outside Runway To Outside Runway
79"
Motor
1HP, 110 Volt
Lift Color Options
Black
