Tire Changer – R145DR | Tiltback VSC Tire Changer
Ready to Order?
$10,778.00
The R145DR is an automatic tire changer with an innovative electric motor inverter, which gives the ability to regulate the chucking table rotation speed to reduce the stress on the bead to avoid any damage to the tire. This tire machine is also equipped with the Fast Inflation (FI) configuration.
- Automatic Tire Changer
- FI Configuration (quick inflation for tubeless tires)
- 220V power-driven motor
- Invemotor 0-16 Variable Speed Control
- Designed for Large and Wide Tires
- Shown with standard helper included
- Hand operated bead breaker handle
Features
Galvanized double-acting bead breaker designed to protect alloy rims.
Double synchronization: perfect load distribution for maximum durability.
Maximum rigidity with 2.4″ x 2.4″ horizontal shaft.
Removable pedal unit for easy maintenance.
Quick inflation valve for tubeless tires. Pedal-operated inflation device complete with inflator valve and pressure gauge.
Air filter and lubricator included.
Specifications
Technical Data | R145D |
Motor | 180/260V (60Hz) / 1ph 0,75kW |
Maximum torque to chuck | 885 Ft/L bs (1200 Nm) |
Self-centring lock: external | 10”- 26” |
Self-centring lock: internal | 12”- 28,5” |
Tool working span | 8”- 32” |
Maximum tire diameter | 45” (1143mm) |
Maximum tire width | 17” (431mm) |
Bead breaker cylinder power at 145 psi | 6,745 lbs/force |
Power supply Motor | 220v / 1Ø / 60 Hz 1 Hp |
shop equipment usa - Contact Form
Features
Compared to competitor’s models the R1150 is both simpler to operate and simpler to maintain. This tire changer is powerful using a 220v inverter motor, torque is always available when needed. The driver motor offers the operator true variable speed control so rotation speed can be customizable. The R1150 is built for maximum performance and includes pneumatic help device, wheel lift, and a full range of bead clamp devices and other adapters. This tire changer is great on low profiles, runflats, exotic rims, and other specialty jobs while also able to change difficult light truck combinations such as 17.5” and 19.5” super duty wheels.
Arm head enters between bead and rim, levering on the rim the tool pulls up on the bead, minimizing tire stress.
Safe and easy mounting with a non-abrasive tool,
roller and rotating helper.
