R155Pro3D
Ready to Order?
$7,876.00
Equipped with all the features for the most demanding professional. Easy operation thanks to interactive inputs, which guide the operator during all the phases of the balancing process. Fast balancing process with automatic start when the cover is lowered and automatic stop of the wheel in the external unbalanced position.
- Simple visual display
- Automatic program
- Internal data gauge
- Space saving footprint
Automatic Lock Position
When the cover is lowered, the R155 automatically begins to spin the shaft.
The balancer automatically stops in
the external unbalanced position.
The balancer automatically rotates
to the internal side.
Finally, it automatically stops in
the internal unbalanced position.
The R180’s laser pointer shows techs the exact positioning for weights.
The R180’s display walks techs through the process
with specific, easy-to-understand icons on the screen.
Standard accessories include a Caliper, 7 Collets, Quick-Locking Wingnut, Rubber Ring Protector, Light Duty Truck Cone,
Calibration Weight, and Weight Pliers.
Linked directly to a standard monitor, the durable touch pad allows for a “gloved” input protecting the monitor from grease and grime.
Linked directly to a standard monitor, the durable touch pad allows for a “gloved” input protecting the monitor from grease and grime.
Linked directly to a standard monitor, the durable touch pad allows for a “gloved” input protecting the monitor from grease and grime.
Gallery
R180 Visual Display
R180 Wheel Balancer Training
R155/R180 Grams to Oz & Bare Shaft Calibration
Specifications
Technical Data | R155 |
Wheel Diameter | 10″ – 30″ automatic |
Tire Width | 1.5″ – 22″ |
Tire Diameter | 44″ |
Max Assembly Weight | 154 lbs. (70kg) |
Read Out Accuracy | 1g |
Cycle Time | 6 Seconds |
Rotation Speed (rpm) | <100 |
Power Supply | 110v / 60 Hz / 1Ø |
