R155Pro2D
Ready to Order?
$7,876.00
A no-nonsense balancer with digital display. Program 12 features into this balancer to handle car and light truck tires assemblies. Automatic distance plus diameter measurements caliper. Automatic ALU S program.
- 2D Data Entry With Data Set Arm
- 7 Piece Collet Set Standard
- Small Lt truck Cone Standard
- Side Storage board Standard
- Split Weight / Hidden Weight Mode
- Positioning Pedal
Automatic Lock Position
Automatic stop in
the external unbalanced position.
The balancer automatically rotates
to the internal side.
Automatic stop in
the internal unbalanced position.
Automatic Distance + Diameter Measurement
Caliper | Automatic ALU S Program.
Hidden Weights Program
Perform aluminum wheel balancing above the spokes of the wheel.
Standard Accessories
Caliper, 7 Collets, Quick-Locking Wingnut,
Rubber Ring Protector, Light Duty Truck Cone,
Calibration Weight, and Weight Pliers
Gallery
Rotary R148 Hidden Weights
R180 Wheel Balancer Training
R155/R180 Grams to Oz & Bare Shaft Calibration
R180 Visual Display
R180 Wheel Balancer Training
R155/R180 Grams to Oz & Bare Shaft Calibration
Specifications
Technical Data | R155 |
Wheel Diameter | 10″ – 30″ automatic |
Tire Width | 1.5″ – 22″ |
Tire Diameter | 44″ |
Max Assembly Weight | 154 lbs. (70kg) |
Read Out Accuracy | 1g |
Cycle Time | 6 Seconds |
Rotation Speed (rpm) | <100 |
Power Supply | 110v / 60 Hz / 1Ø |
