Perform accurate alignments up to 30% faster from anywhere in the bay!
R1085
Ready to Order?
$22,075.00
Perform accurate alignments up to 30% faster from anywhere in the bay! The portable, tower-free R1085 is tablet operated and WIFI ready – no computer or monitor! The operator controls the process remotely with an integrated Android Tablet, which means fewer steps and quicker alignments!
Plus, the R1085 is engineered with advanced 3D target imaging technology and equipped with tire grabbing clamps, fixed cameras and remote-controlled sensors.
Perform accurate alignments up to 30% faster from anywhere in the bay! The portable, tower-free R1085 is tablet operated and WIFI ready – no computer or monitor! The operator controls the process remotely with an integrated Android Tablet, which means fewer steps and quicker alignments!
Plus, the R1085 is engineered with advanced 3D target imaging technology and equipped with tire grabbing clamps, fixed cameras and remote-controlled sensors.
- Tower-free system – No tower. No limitations. No Interruptions.
- Easy-to-use software with on rack test drive system
- Quick locking clamps – Best in the market!
- Patented 3D targets – Increased accuracy
- Fixed cameras – Solid vision technology
- Tower Free System
- No Minimum Bay Size Required
- No Compensation or Roll Back
- No Interruptions
- No Limitations
Maximize available workspace.
Don’t give up valuable bay space in your shop.
No physical rolling or pushing of the vehicle to make runout compensation. Automatic and instant 3D target visualization. *FOR MOST VEHICLES
Perfect transmission signals. Always.
Can be used at any height! No need to dedicate bays for alignment service only. Use the aligner in more than one bay location with optional sensor supports.
Related products
No tower. No limitation. No interuptions.
On rack test drive program
On rack test drive program
Patented 3D targets – increased accuracy
Specifications
Technical Data | Accuracy | Measuring Range | Total Measuring Range |
Front Axle | |||
Total toe | +/- 2’ | +/- 2° | +/- 20° |
Partial toe | +/- 1′ | +/- 1° | +/- 20′ |
Set-back | +/- 2’ | +/- 2° | +/- 5° |
Camber | +/- 2’ | +/- 3° | +/- 10° |
Caster | +/- 5′ | +/- 10° | +/- 18° |
King-pin | +/- 5′ | +/- 10° | +/- 18° |
Rear Axle | |||
Total toe | +/- 2′ | +/- 2° | +/- 20° |
Partial toe | +/- 1′ | +/- 1° | +/- 20° |
Set-back | +/- 2′ | +/- 2° | +/- 5° |
Camber | +/- 2′ | +/- 3° | +/- 10° |
Thrust angle | +/- 2′ | +/- 2° | +/- 5° |
Power | |||
shop equipment usa - Contact Form
Features
Your content goes here. Edit or remove this text inline or in the module Content settings. You can also style every aspect of this content in the module Design settings and even apply custom CSS to this text in the module Advanced settings.
EASY-TO-USE SOFTWARE WITH ON RACK TEST DRIVE PROGRAM
- No dedicated bay required
- Other systems require up to 10 ft. of space in front of the lift
- Works with any alignment lift at any height without interruptions to the targets
EASY-TO-USE SOFTWARE WITH ON RACK TEST DRIVE PROGRAM
- Position magnetized tablet to the cart, lift or vehicle during measuring process
- Animated step-by-step instructions guide the process and provide live adjustment illustrations with easy-to-read results
- Program double checks your alignment from the rack – no need for techs to physically test drive the vehicle
QUICK LOCKING CLAMPS – BEST IN THE MARKET!
- 4-point clamps don’t tighten around the wheel, eliminating damage to rims
- No grabber claw depth
- Less clamp distortion
PATENTED 3D TARGETS – INCREASED ACCURACY
- Lightweight with no electronic components inside
- Built in leveling display
- No maintenance required
FIXED CAMERAS – SOLID VISION TECHNOLOGY
- Cameras automatically position and recognize targets for precise reading in seconds
- Rubber armored, high resolution measuring heads
- Digital display keyboard with remote-controlled function
- No adapters required with obtaining caster readings
- True 3d image is mapped compared to a manipulated flat target
